APPLICATIONS
For driving spikes in railroad, construction, mining, and plant maintenance.
FEATURES
- Swivel air inlet connection
- Internal oiler
- Rubber handle grip with 4-bolt backhead construction
- 90 lb Class Spike Driver
SCHEMATIC
KT-SD90 Schematic: Click Here
SPECIFICATIONS
| Model Names | KT-SD90 |
| Net Weight | 89.5 lbs (40.5 kg) |
| Length | 26.5 in (673 mm) |
| Bore | 2.625 in (66.67 mm) |
| Stroke | 6.0625 in (154 mm) |
| Blows Per Minute | 1250 |
| Air Inlet (NPT) | 3/4 in (19 mm) |
| Air Consumption* | 75 cfm (2.1 m3/m) |
| *estimated |
*For optimum performance, do not operate tool above 90 PSI (6 bar) working pressure.
WARNING: Always disconnect the air supply before changing chisels or dismantling the tool for service or repair. For maximum safety, we advise the installation of a shut-off valve at the end of the air line.
Do NOT exceed 100 PSI (7BAR) working pressure.
